规格型号 Model	大卷制厚度 Max.rolling thickness (mm)	大预弯厚度 Max.pre-rolling thickness (mm)	大卷制宽度 Plate width (mm)	上辊直径 Diameter of upper roller (mm)	主电机功率 Main motor power (kw)
W11SNC-12X2000	12	10	2000	250	5.5
W11SNC-16X2000	16	12	2000	225	7.5
W11SNC-16X2500	16	12	2500	300	11
W11SNC-18X3000	18	14	3000	350	11
W11SNC-20X3000	20	16	3000	375	15
W11SNC-25X2500	25	20	2500	380	15
W11SNC-30X2500	30	25	2500	410	22
W11SNC-30X3000	30	25	3000	450	30
W11SNC-32X3000	32	28	3000	480	30
W11SNC-35X2500	35	30	2500	460	30
W11SNC-35X3000	35	30	3000	510	37
W11SNC-40X2500	40	35	2500	500	37
W11SNC-40X3000	40	35	3000	540	45
W11SNC-40x4000	40	32	4000	610	45
W11SNC-45x3000	45	40	3000	590	45
W11SNC-45x4000	45	40	4000	660	45
W11SNC-50x4000	50	45	4000	700	55
W11SNC-55x3000	55	45	3000	620	55
W11SNC-55x4000	55	50	4000	750	55
W11SNC-60x3000	60	50	3000	650	55
W11SNC-60x4000	60	55	4000	780	75
W11SNC-65x4000	65	60	4000	810	75
W11SNC-70x3000	70	60	3000	710	75
W11SNC-70x4000	70	65	4000	820	75
W11SNC-75x3000	75	65	3000	740	75
W11SNC-80x3000	80	70	3000	760	75
W11SNC-80x4000	80	75	4000	860	90
W11SNC-90x3000	90	80	3000	790	90
W11SNC-100x3000	100	90	3000	820	90
W11SNC-110x4000	110	90	4000	940	90
W11SNC-120x3000	120	100	3000	860	90
W11SNC-120x4000	120	100	4000	990	110
W11SNC-130x3000	130	110	3000	960	2x75
W11SNC-160x3000	160	120	3000	1080	2x75
W11SNC-160x4000	160	130	4000	1260	2x90
